D3024 High Speed Centrifuge

Technical Specifications

Specification	Details
Model	D3024
Cat.No.	9033000121
Speed range	15000rpm(200-15000rpm), increment:10rpm
Max. RCF	21380×g, increment:10×g
Speed accuracy	±20 rpm
Rotor capacity	1.5/2mL ×24 \| 0.2/0.5mL ×36 \| PCR-8 strips×4 \| 5mL ×12 \| 5mL×18
Run time	30sec-99min/Continuous
Acceleration/Braking time	25s↑25s↓
Display	LCD
Power	200W
Voltage/Frequency	Single-phase, AC200V-400V, 50Hz/60Hz, 5A,AC100V-120V, 50Hz/60Hz, 8A
Noise level	≤64dB
Motor type	Brushless DC motor
Dimensions[WxDxH]	364×280×266mm
Weight	12kg
Safety performance	Dual door interlock, Over-speed detection, Automatic internal diagnosis
Other functions	Speed/RCF switch; Short-time run function; sound-alert function

Description

The D3024 High Speed Centrifuge is a high speed micro centrifuge supplied for laboratory and research use in Riyadh, Dammam, Dhahran, Jubail, Al Khobar, Jeddah, Makkah, Yanbu and Jazan across Saudi Arabia.

fast cooling of the rotor and low energy consumption
3-layer sealed rotors ensure safe centifugation
Brushless motor drive, maintenance free
Safety features include door interlock; excessive speed and temperature detection; automatic self-diagnostics
Outstanding aluminum alloy rotors fully autoclavable at 121℃ temperature and high pressure disinfection
Five rotors are optional complete with 24 places 1.5/2.0mL tubes,5.0mL, 0.2mL and 0.5mL tubes with adapters
Complies with applicable CE, UKCA, FCC, ICES, and RoHS requirements and has also obtained CB and cTUVus certifications
