DM1424 High Speed Centrifuge

Technical Specifications

Specification	Details
Model	DM1424
Speed range	200-12000rpm, increment: 10rpm
Max. RCF	13680×g
Speed accuracy	±20
Rotor capacity	24×capillary tubes
Run time	30sec-99min/Continuous
Acceleration/Braking time	30s↑30s↓
Display	LCD
Power	160W
Voltage/Frequency	Single-phase, 200V-240V,50Hz/60Hz, 5A; 100V- 120V,50Hz/60Hz, 5A
Motor type	Brushless DC motor
Dimensions[WxDxH]	280×364×274mm
Weight	10.5kg
Safety performance	Door interlock,Overspeed detector; Automatic internal diagnosis, Automatic rotor identification
Other functions	Speed/RCF switch; Short-time run function; sound-alert function

Description

The DM1424 High Speed Centrifuge is a high speed micro centrifuge supplied for laboratory and research use in Riyadh, Dammam, Dhahran, Jubail, Al Khobar, Jeddah, Makkah, Yanbu and Jazan across Saudi Arabia.

• Speed range of 200-12000 rpm Precise and independent control of speed and time
• Easy operation with intuitive menu and LCD display
• Maintenance-free brushless DC motor
• Pulse operation for fast and convenient quick spins
• Advance features include speed/RCF switch; short-time run function; audible alert function
• Safety features include door interlock, overspeed detector;over-temperature detector; automatic internal diagnosis and automatic rotor identification
• Complies with applicable CE, UKCA, FCC, ICES, and RoHS requirements and has also obtained CB and cTUVus certifications.
