Technical Specifications

Specification Details
Model DHP4-550
Cat.No. 8021502211(Main Unit)/8121502211(Set)
Work plate Dimension 100x100mm(4 inch)
Work plate material Glass ceramic
Heating temperature range Room Temp.-550℃,increment1℃
Temperature display LCD
Time display LCD
Temperature control accuracy ±1℃ (<100℃) | ±1%(>100℃)
Temperature display accuracy 0.1℃
External temperature sensor PT1000(accuracy±0.2℃ )
“Hot” warning 50℃
Overheating temperature protection 580℃
Heating position 1
Timer function 1min-99h59min
Protection class IP21
Power 430W
Heating output 410W
Voltage,Frequency 100-120/200-240V,50/60Hz
Dimension[WxDxH] 270x175x108mm
Weight 1.8kg
Permissible ambient temperature 5-40℃
Permissible ambient humidity 80%RH

Description

The DHP4-550 LCD Glass Ceramic Hotplate with is a hotplate supplied for laboratory and research use in Riyadh, Dammam, Dhahran, Jubail, Al Khobar, Jeddah, Makkah, Yanbu and Jazan across Saudi Arabia.

  • Product Features:
  • Ceramic top plate with excellent corrosion resistance, capable of withstanding strong acids, strong alkalis, and high temperatures; easy to clean if solvents, oils, or other contaminants are accidentally spilled.
  • Corrosion-resistant all-metal housing provides efficient heat dissipation and reliable fire protection.
  • High-efficiency diversion platform and waterproof edge design help prevent liquids from entering the unit and corroding electronic components.
  • Safety lock prevents accidental changes to the operating status.
  • Buzzer alarm: when the unit malfunctions or the timer countdown ends, the buzzer emits a “beep-beep-beep” alert.
  • Residual heat warning: when the plate temperature is above 50°C and heating is turned off, the screen flashes “HOT.” Even after the power is switched off, the display continues flashing “HOT” to warn of the high temperat
  • Dual independent safety circuits continuously monitor the unit. In case of overheating or sensor failure, the unit displays an error and stops heating. In case of a short circuit, the unit automatically cuts off power to
  • LCD display shows both set values and real-time values for time and temperature, providing clear and intuitive operation.
  • Timer function with a timing range of 1 min to 99 h 59 min.

0.00 ر.س

Available on backorder
