4/6 Channel LCD Digital Hotplate Magnetic MS-H280-S6

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S6

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S4

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S4 - view 2

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S4 - view 3

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S4 - view 4

4/6 Channel LCD Digital Hotplate Magnetic Stirrer, MS-H280-S4 - view 5

Technical Specifications

Specification	Details
Model	MS-H280-S6
Cat.No.	8030351112
Work plate Dimension	Ø134mm
Work plate material	Aluminum with ceramic coating
Max. stirring quantity [H2O]	3LX6
Speed range	200-1500rpm
Speed display	LCD
Temperature display	LCD
Heating temperature range	25-280℃
Temperature control accuracy	±1℃(<100℃)， ±1%(>100℃)
Heating temperature control accuracy test conditions	1 L beaker with 500 mL water, 50 °C, 40 mm magnetic stir bar, 500 rpm; 1 L beaker with 500 mL silicone oil, 120 °C, 40 mm magnetic stir bar, 500 rpm.
Temperature display accuracy	0.1℃
External temperature sensor	PT1000(accuracy±0.2℃)
“Hot” warning	50℃
Overheating temperature protection	420℃
Motor type	Brushless DC motor
Stirring positions	6
Max. magnetic bar length	40mm
Protection class	IP21
Motor rating output	15WX2
Heating power	1800WX2
Power	1815WX2
Voltage,Frequency	200-240V，50Hz
Dimension [WxDxH]	564X523X127mm
Weight	12.7Kg
Permissible ambient temperature	5-40℃
Permissible ambient humidity	80% RH

Description

The 4/6 Channel LCD Digital Hotplate Magnetic (MS-H280-S6) is a magnetic hotplate stirrer supplied for laboratory and research use in Riyadh, Dammam, Dhahran, Jubail, Al Khobar, Jeddah, Makkah, Yanbu and Jazan across Saudi Arabia.

Product Features:
4/6 channels with independently control of start/stop, temperature, speed and display for better parallel experiment control.
Ceramic coating aluminum work plate with fast heat transmission and strong resistance to corrosion.
Powerful, rapid heating with accurate PID temperature control
Spark-free DC brushless motor with extended life and no maintenance
Compatible with various heating block or reaction vessels for a variety of application scenario
Ultra space-saving with 4/6 channel integrated in one instrument
“HOT” warning flashes on the LCD display if the work plate temperature is above 50℃ after the user turn off the power switch.
Two independent safety circuits keep monitoring the instrument.When overheating is detected and the sensor malfunctions, it will stop heating and sound alarm; When short circuit is detected, it will cut off the power to
Reliable safety mechanism, compliant to IEC61010-1UL61010-1BSEN61010-1CANCSA-C22.2NO.61010-1and all other safety regulations of laboratory heating devices, competent with tasks without human surveillance.
